Two channel
Timer
daily, weekly program in one device,
automatic conversion
summer / winter time
|
Digital Timer w Display
Field-selectable time ranges 0.001 second to 9999 hours
12-24 VDC
|
Multi-function Timer
0.1s to 10 days
250V 10 Amp.NO/NC
DIN mount.
|
ON
/ Off Delay Timer
12- 24 VDC 5 Functions
0.1 Sec. to 300 Hr.
Octal socket with DIN mount
|
|
|
|
|
|
Year - Month Timer
daily, weekly,
month and Year
program in one device, automatic summer / winter time
|
Digital Timer w Display
Field-selectable time ranges 0.001 second to 9999 hours
120/220VAC |
Timer 0.05m
-10 hours
Selectable timing range Time delay setting, Repeat On delay,
Off delay. Multi voltage |
OFF Delay
Timer
0.5 to 6 Min. 24 VAC/DC,
10 Amp. DPDT
Octal base
|
|
|
|
|
|
Dual
Multifunction Timer
time range from
0,01s-60 hrs and 10 functions DIN w LED
|
Digital Counter
High-speed
response allows 1,000 counts per second
12,24V
|
ON Delay
Timer
24 VDC
0.1
Sec. to 9990 hrs
Octal socket with DIN mount. |
ON Delay
Timer
12 VDC
0.1
Sec. to 9990 hrs
Octal socket with DIN mount. |
|
|
|
|
|
Electronic
Single Shot
Adjustable time
250V 10Amp. NO/NC
Base w
DIN mount. |
Electronic Latch
Relay
12 VDC, SPDT,10 Amp.
250V 10Amp. NO/NC
Base w
DIN mount. |
ON Delay Timer
0.5 to 60
Sec. 24 V
Octal socket with DIN mount. |
Twin
Setting Repeat Cycle
Two timers in one case,
independent setting of both "on" and "off"
time 24 VAC/DC |
|
|
|
|
|
7
Day Heavy-Duty
Programmable Digital
Timer
LCD Display. Manual override.
Ratings: 15 Amp, 500
Watts,
1/3 H.P. 120 VAC, 3-prong
grounded plug and receptacle.
98 ON/OFF settings per
week |
30A. Power
relay 12VDC 30 Amp.
120/277 V,AC
3 HP- 277 V, 1.5 HP - 120V
|
12 Amp. Relay 1 Pole
12VDC coil 60 mA.
277 VAC SPST
General purpose
Plug-in relay and DIN mount |
Real-time
Clock 4 Ch
Year, month, day, hour minute and second setting
6 Digital AC inputs
4
Relay outputs PLC. |
|
|
|
|
|
Digital Timer w Display
Field-selectable time ranges 0.001 second to 9999 hours |
|
Relay 1
Pole NO/NC
12VDC coil 40 mA.
10 Amp.125 VAC DPDT |
Relay 2 Pole
NO/NC
240VAC coil 15 mA.
10 Amp. 250 VAC DPDT |
|
|
|
|
|
|
|
|
|
Glossary
NC Normally closed contact
NO Normally open contact |
SPST Single pole single throw
SPDT Single pole double throw |
DPDT Double pole double throw |
Amp. Maximum current rating |
