Mitsubishi PLC software

PLC Programming Software (®Windows Based)

Hardware Specifications

A/QnA Specifications

AnSH Specifications

GX Developer GX and GX DEV IEC are Windows based programming package that supports the full line of Mitsubishi PLCs. GX-DEV has support for the following PLCs: FX0(S), FX0N, FX1, FX1S/1N, FXU/FX2C, FX2N(C), A0J2H, A1FX, A1S(S1), A1SJ, A1SH, A1SJH, A1N, A2C, A2CJ, A2N(S1), A2S(S1), A2SH(S1), A3N, A2A(S1), A3A, A2U(S1), A2US(S1), A2AS(S1), A2AS-S30, A2AS-S60, A2USH-S1, A3U, A4U, Q2A, Q2AS(H), Q2AS1, Q2AS(H)S1, Q3A, Q4A, Q4AR, Q02(H)-A, Q06H-A, Q00J, Q00, Q01, Q02(H), Q06H, Q12H, Q25H, A171SH, A172SH and A273UH(S3).

GX-DEV is capable of communicating to a Mitsubishi PLC by means of the programming port, Ethernet, modem, and Mitsubishi networks (including MelsecNet/10 and CC-Link). For connecting to the PLC front port, the SC09 programming cable must be purchased separately. Also included on the GX Developer CD are the GX Converter and GX Explorer software add-ons.

Part Number	Description
GX-DEV-C1	Single user license – can be used on 1 computer at a time Includes 1 CD containing both software and electronic manuals
GX-DEV-C5	5 user license – can be used on up to 5 computers at a time Includes 1 CD containing both software and electronic manuals
GX-DEV-1 IEC	Single user license GX IEC Developer is more than a powerful IEC 1131.3 programming and documentation package

GX Developer–FX
As an alternative for FX PLC users, GX Developer FX (GX-DEV-FX) is a scaled down version of GX-DEV supporting the FX Series PLCs. GX-DEV-FX is 100% compatible with the full blown version of GX-DEV and files can be shared between the two (limited to FX PLC programs). Customers who have already purchased GX-DEV do not need GX-DEV-FX as all the functionality for the FX PLCs is the same in both packages. Also included on the GX Developer-FX CD is the GX Converter software add-on.

Part Number	Description
GX-DEV-FX-C1	Single user license – can be used on 1 computer at a time Includes 1 CD containing both software and electronic manuals
GX-DEV-FX-C5	5 user license – can be used on up to 5 computers at a time Includes 1 CD containing both software and electronic manuals.
GX-DEV-FX-C10	10 user license – can be used on up to 10 computers at a time Includes 1 CD containing both software and electronic manuals

Note: All manuals come free of charge on the software CD-ROM in Adobe Acrobat® Reader format. A free copy of the Acrobat Reader program is also included on the software CD. If hard copies of the manuals are desired, please refer to the manual part numbers listed.
